Main

• Sensor1280х1024 @ 12 µm (NETD <40 mK)
• Objective lens 50mm/F1.0
• Magnification, x 2 - 16
• Field of view (HxV), degrees / m@100m17.5/30.7
• Detection range, 2515 yards

Sensor

• Type uncooled
• Resolution, 1280х1024
• Pixel pitch, 12um
• NETD, mK <40
• Frame rate, 50Hz

Optics

• Objective lens 50mm/F1.0
• Magnification, x2 - 16
• Field of view (HxV), degrees / m @ 100 m17.5/30.7
• Interpupillary distance adjustment, 63 – 74mm
• Eye relief, 15mm
• TypeAMOLED

Display

• Resolution, pixels1280х960

Laser Rangefinder

• Safety class for laser equipment according to IEC 60825-1:20141
• Wavelength, nm905
• Max. measuring range, yards1640
• Measurement accuracy, m± 1

Video Recorder

• Video / photo resolution, pixel1280х960
• Video / photo format.mp4 / .jpg
• Built-in memory, GB64

Wi-Fi

• Wireless ProtocolWi-Fi
• Wireless StandardIEEE 802.11 b/g/n/ac (WPA)
• Frequency, GHz2.4 / 5

Environmental Characteristics

• Degree of protection, IP code (IEC60529)IPХ7 (waterproof)
• Operating temperature range, -13 – 122F

Connections and Compatibilities

• Mount, type1/4" socket
• Supported ApplicationStream Vision 2

Power Supply

• Output voltage, V3.7
• Battery typeDual Li-Ion internal + Pulsar APS3 external
• Capacity, mAh3200 (external) + 4000 (internal)
• Operating time on battery pack (at t=71°F), h *6
• External power supply, V5V, 9V (USB Type-C Power Delivery)

Weight & Size

• Body materialMagnesium alloy
• Dimensions, mm197x140x72
• Weight, lbs2 (batteries included)

Trade Data

• SKU (Model #)77486
